B-100 Series Particle Counting System

Particle Size Ranges Number of Size Range Channels
Size Range Sensor Model Number of Channels Counter Model
1-150µm D1 3 C3
2-300µm D2 8 C8
20-1500µm D3 10 C10


System Specifications:

  • Principle of Detection - Laser Light Obscuration
  • Concentration Limit - 25,000 particles/ml
  • Output - RS232 computer
  • Calibration Method - NIST traceable spheres or SAE Test Dust
  • Flow Rate - 60 cc/.min
  • Maximum Pressure - 150 psig (pressure mode only)
  • Maximum Fluid Temp - 66 C
  • Laser Life Expectancy: 100,000 hours

Other Related IBR Equipment and Services

  • Contract particle counting and sizing of process fluids, products, and component cleanliness
  • Component cleanliness test system
  • Contract filter testing at flows up to 300 gpm in liquids or 5000 scfm in air
